LILYGO SIM

2025-04-01

Model Comparison

Product	Module	QWIIC	Seamless power switching	GNSS routing to SOC	GNSS PPS	eSIM Pad	BMS	Camera Interface	DeepSleep Current	Pin compatible
T-A7670X	ESP32-WROVER-B(N4R8)	❌	❌	❌	❌	❌	✅	❌	Avg: 157uA	❌
T-A7608X	ESP32-WROVER-B(N4R8)	❌	❌	❌	❌	❌	✅	❌	Avg: 240uA	❌
T-SIM7000G	ESP32-WROVER-B(N4R8)	❌	❌	❌	❌	❌	✅	❌	Avg: 500uA	❌
T-SIM7600G	ESP32-WROVER-B(N4R8)	❌	❌	❌	❌	❌	✅	❌	Avg: 200uA	❌
T-SIM7080G-S3	ESP32-S3-WROOM-1(N16R8)	❌	❌	❌	❌	❌	❌	✅	Avg: 1.1mA	❌
T-SIM7670G-S3	ESP32-S3-WROOM-1(N16R8)	❌	❌	❌	❌	❌	✅	❌	Avg: 497uA	❌
T-A7608X-S3	ESP32-S3-WROOM-1(N16R8)	❌	❌	❌	❌	❌	✅	❌	Avg: 368uA	❌
T-A7670X-S3 -Standard	ESP32-S3-WROOM-1(NR16R2)	✅	✅	✅	✅	✅	✅	✅	Avg: 314uA	✅
T-SIM7670G-S3 -Standard	ESP32-S3-WROOM-1(NR16R2)	✅	✅	✅	✅	✅	✅	✅	Avg: 147uA	✅
T-SIM7000G-S3 -Standard	ESP32-S3-WROOM-1(NR16R2)	✅	✅	✅	❌	✅	✅	✅	Avg: 166uA	✅
T-SIM7080G-S3 -Standard	ESP32-S3-WROOM-1(NR16R2)	✅	✅	✅	❌	✅	✅	✅	Avg: 128uA	✅
T-SIM7600G-S3 -Standard	ESP32-S3-WROOM-1(NR16R2)	✅	✅	❌	❌	✅	✅	✅	Avg: 128uA	✅

ESP32-WROVER-B(N4R8): 4MB Flash , 8MB PSRAM
ESP32-S3-WROOM-1(N16R8): 16MB Flash , 8MB PSRAM(Octal SPI)
ESP32-S3-WROOM-1(N16R2): 16MB Flash , 2MB PSRAM(Quad SPI)
The deep sleep current test record can be found in DeepSleep.ino
SIM7000G/SIM7080G/SIM7600G do not have PPS function, so this function is not available.

A7670G / A7670E / A7670SA are collectively referred to as A7670X.

A7672G is identical to A7670G, with only a different name.

A7608SA-H / A7608E-H / A7608E / A7608SA are collectively referred to as A7608X.

SIM7670G uses the Qualcomm platform.

A7670X uses the Asrmicro platform.

The usage is exactly the same.

The only difference lies in the internal chip manufacturing process of the module

Removed:

Added:

A7670E-LNXY-UBL This version does not support voice and SMS functionalities.

T-2Can

SIM7600E
